EFM32G Data Sheet
TQFP48 Package Specifications
9.2 TQFP48 PCB Layout
a
p8
p7
p6
p1
b
c
e
p2
p5
p3
p4
d
Figure 9.2. TQFP48 PCB Land Pattern
Table 9.2. TQFP48 PCB Land Pattern Dimensions (Dimensions in mm)
Symbol
Dim. (mm)
1.60
Symbol
P1
Pin Number
Symbol
P6
Pin Number
a
b
c
d
e
1
36
37
48
0.30
P2
12
13
24
25
P7
0.50
P3
P8
8.50
P4
8.50
P5
a
b
c
e
d
Figure 9.3. TQFP48 PCB Solder Mask
Table 9.3. TQFP48 PCB Solder Mask Dimensions (Dimensions in mm)
Symbol
Dim. (mm)
1.72
a
b
c
d
e
0.42
0.50
8.50
8.50
