EFM32G Data Sheet
QFN64 Package Specifications
10. QFN64 Package Specifications
10.1 QFN64 Package Dimensions
49
64
48
1
33
16
32
17
m
m
Figure 10.1. QFN64
Note:
1. Dimensioning & tolerancing confirm to ASME Y14.5M-1994.
2. All dimensions are in millimeters. Angles are in degrees.
3. Dimension 'b' applies to metallized terminal and is measured between 0.25 mm and 0.30 mm fromthe terminal tip. Dimension L1
represents terminal full back from package edge up to 0.1 mm isacceptable.
4. Coplanarity applies to the exposed heat slug as well as the terminal.
5. Radius on terminal is optional.
Table 10.1. QFN64 (Dimensions in mm)
Symbol
Min
0.80
0.00
Nom
0.85
Max
0.90
0.05
A
A1
A3
b
—
0.203 REF
0.30
0.25
0.35
D
9.00 BSC
9.00 BSC
7.20
E
D2
E2
7.10
7.10
7.30
7.30
7.20
silabs.com | Building a more connected world.
Rev. 2.10 | 185
