EFM32G Data Sheet
LQFP100 Package Specifications
SYMBOL
D
MIN
NOM
MAX
x
y
x
y
16 BSC
16 BSC
14 BSC
14 BSC
0.5 BSC
0.6
E
D1
E1
e
body size
lead pitch
L
0.45
0.75
footprint
L1
1 REF
3.5º
θ
0º
0º
7º
—
θ1
—
θ2
11º
11º
0.08
0.08
0.2
12º
13º
13º
—
θ3
12º
R1
R1
S
—
—
0.2
—
—
package edge tolerance
lead edge tolerance
coplanarity
aaa
bbb
ccc
ddd
eee
0.2
0.2
0.08
0.08
0.05
lead offset
mold flatness
The LQFP100 Package uses Nickel-Palladium-Gold preplated leadframe.
All EFM32 packages are RoHS compliant and free of Bromine (Br) and Antimony (Sb).
For additional Quality and Environmental information, please see: http://www.silabs.com/support/quality/pages/default.aspx
