27.2. PCA0 Interrupt Sources
Figure 27.3 shows a diagram of the PCA interrupt tree. There are five independent event flags that can be
used to generate a PCA0 interrupt. They are as follows: the main PCA counter overflow flag (CF), which is
set upon a 16-bit overflow of the PCA0 counter, an intermediate overflow flag (COVF), which can be set on
an overflow from the 8th, 9th, 10th, or 11th bit of the PCA0 counter, and the individual flags for each PCA
channel (CCF0, CCF1, CCF2, CCF3, CCF4, and CCF5), which are set according to the operation mode of
that module. These event flags are always set when the trigger condition occurs. Each of these flags can
be individually selected to generate a PCA0 interrupt, using the corresponding interrupt enable flag (ECF
for CF, ECOV for COVF, and ECCFn for each CCFn). PCA0 interrupts must be globally enabled before any
individual interrupt sources are recognized by the processor. PCA0 interrupts are globally enabled by set-
ting the EA bit and the EPCA0 bit to logic 1.
(for n = 0 to 2)
PCA0CPMn
PCA0CN
PCA0MD
PCA0PWM
P E C C M T P E
W C A A A O W C
M O P P T G M C
1 M P N n n n F
C C C C C C C C
F R C C C C C C
F F F F F F
C WW C C C E
I D D P P P C
D T L S S S F
L E C 2 1 0
K
A C E
C C
L L
S S
E E
L L
1 0
R O C
S V O
E F V
L
5 4 3 2 1 0
6 n n n
n
n
PCA Counter/Timer 8, 9,
10 or 11-bit Overflow
Set 8, 9, 10, or 11 bit Operation
0
1
PCA Counter/Timer 16-
bit Overflow
0
1
EPCA0
EA
ECCF0
Interrupt
Priority
Decoder
0
1
0
1
0
1
PCA Module 0
(CCF0)
ECCF1
ECCF2
0
1
PCA Module 1
(CCF1)
0
1
PCA Module 2
(CCF2)
ECCF3
ECCF4
ECCF5
0
1
PCA Module 3
(CCF3)
0
1
PCA Module 4
(CCF4)
0
1
PCA Module 5
(CCF5)
Figure 27.3. PCA Interrupt Block Diagram
27.3. Capture/Compare Modules
Each module can be configured to operate independently in one of six operation modes: Edge-triggered
Capture, Software Timer, High Speed Output, Frequency Output, 8 to 11-Bit Pulse Width Modulator, or 16-
Bit Pulse Width Modulator. Each module has Special Function Registers (SFRs) associated with it in the
CIP-51 system controller. These registers are used to exchange data with a module and configure the
module's mode of operation. Table 27.2 summarizes the bit settings in the PCA0CPMn and PCA0PWM
registers used to select the PCA capture/compare module’s operating mode. All modules set to use 8, 9,
10, or 11-bit PWM mode must use the same cycle length (8-11 bits). Setting the ECCFn bit in a
PCA0CPMn register enables the module's CCFn interrupt.
