C8051F39x/37x
SFR Definition 14.3. CPT0MX: Comparator0 MUX Selection
Bit
7
6
5
4
3
2
1
0
CMX0N[3:0]
R/W
CMX0P[3:0]
R/W
Name
Type
Reset
1
1
1
1
1
1
1
1
SFR Address = 0x9F; SFR Page = All Pages
Bit
Name
Function
7:4 CMX0N[3:0]
Comparator0 Negative Input MUX Selection.
0000:
0001:
0010:
0011:
P0.1
P0.3
P0.5
P0.7
P1.1
P1.3
P1.5
P1.7
0100:
0101:
0110:
0111:
1000:
1001:
1010-1111:
P2.1 (C8051F390/1/4/5 and C8051F37x Only)
P2.3 (C8051F390/1/4/5 and C8051F37x Only)
None
3:0 CMX0P[3:0]
Comparator0 Positive Input MUX Selection.
0000:
0001:
0010:
0011:
P0.0
P0.2
P0.4
P0.6
0100:
0101:
0110:
P1.0
P1.2
P1.4
0111:
P1.6
1000:
1001:
1010-1111:
P2.0 (C8051F390/1/4/5 and C8051F37x Only)
P2.2 (C8051F390/1/4/5 and C8051F37x Only)
None
Preliminary Rev. 0.71
79
