BATTERY PROTECTION IC FOR 1-CELL PACK
S-8211C Series
Rev.5.0_00
(5) S-8211CAF, S-8211CAO, S-8211CAP, S-8211CAQ, S-8211CBD, S-8211CBO
Table 14
Test
Condi-
tion
Test
Circuit
Item
Symbol
Condition
Min.
Typ.
Max. Unit
DELAY TIME (Ta = 25 °C)
Overcharge detection delay time
Overdischarge detection delay time
Discharge overcurrent detection delay time
Load short-circuiting detection delay time
Charge overcurrent detection delay time
tCU
tDL
tDIOV
tSHORT
tCIOV
−
−
−
−
−
0.96
30
7.2
240
7.2
1.2
38
9
300
9
1.4
46
11
360
11
s
ms
ms
µs
ms
9
9
10
10
10
5
5
5
5
5
DELAY TIME (Ta =
−
40 to
+
85 °C) *1
tCU
tDL
tDIOV
tSHORT
tCIOV
−
−
−
−
−
0.7
20
5
150
5
1.2
38
9
300
9
2.0
65
15
540
15
s
ms
ms
9
9
10
10
10
5
5
5
5
5
Overcharge detection delay time
Overdischarge detection delay time
Discharge overcurrent detection delay time
Load short-circuiting detection delay time
Charge overcurrent detection delay time
µ
s
ms
*1. Since products are not screened at high and low temperature, the specification for this temperature range is guaranteed
by design, not tested in production.
(6) S-8211CAW
Table 15
Test
Test
Item
Symbol
Condition
Min.
Typ.
Max. Unit Condi-
tion
Circuit
DELAY TIME (Ta = 25 °C)
Overcharge detection delay time
Overdischarge detection delay time
Discharge overcurrent detection delay time
Load short-circuiting detection delay time
Charge overcurrent detection delay time
tCU
tDL
tDIOV
tSHORT
tCIOV
−
−
−
−
−
0.96
120
3.6
240
7.2
1.2
150
4.5
300
9
1.4
180
5.4
360
11
s
ms
ms
µs
ms
9
9
10
10
10
5
5
5
5
5
DELAY TIME (Ta =
−
40 to
+
85 °C) *1
tCU
tDL
tDIOV
tSHORT
tCIOV
−
−
−
−
−
0.7
83
2.5
150
5
1.2
150
4.5
300
9
2.0
255
7.7
540
15
s
ms
ms
9
9
10
10
10
5
5
5
5
5
Overcharge detection delay time
Overdischarge detection delay time
Discharge overcurrent detection delay time
Load short-circuiting detection delay time
Charge overcurrent detection delay time
µ
s
ms
*1. Since products are not screened at high and low temperature, the specification for this temperature range is guaranteed
by design, not tested in production.
Seiko Instruments Inc.
13
