S5PV210AA0-LA40
•
UART
♦
♦
♦
♦
♦
♦
♦
4 UART with DMA-based or interrupt-based operation
Supports 5-bit, 6-bit, 7-bit, or 8-bit serial data transmit/receive
Rx/Tx independent 256-Byte FIFO for UART0, 64-Byte FIFO for UART1 and 16-Byte FIFO for UART2/3
Programmable baud rate
Supports IrDA 1.0 SIR (115.2Kbps) mode
Loop back mode for testing
Non-integer clock divides in Baud clock generation (BRM)
•
•
•
USB OTG 2.0
♦
♦
♦
Complies with the USB OTG 2.0
Supports high speed up to 480Mbps
On-chip USB transceiver
USB Host 2.0
♦
♦
♦
Complies with the USB Host 2.0
Supports high speed up to 480Mbps
On-chip USB transceiver
HS-MMC/SDIO Interface
♦
♦
♦
♦
♦
Multimedia Card Protocol version 4.0 compatible (HS-MMC)
SD Memory Card Protocol version 2.0 compatible
DMA based or Interrupt based operation
128 word FIFO for Tx/Rx
4 port HS-MMC or 4 port SDIO
•
•
SPI Interface
♦
♦
♦
3 Serial Peripheral Interface Protocol version 2.11 compatible
Rx/Tx independent 64-Word FIFO for SPI0 and 16-Word FIFO for SPI1/2
DMA-based or interrupt-based operation
GPIO
♦
♦
♦
♦
♦
♦
♦
237 multi-functional input/ output ports
Controls 178 External Interrupts
GPA0: 8 in/out port – 2xUART with flow control
GPA1: 4 in/out port – 2xUART without flow control or 1xUART with flow control
GPB: 8 in/out port – 2x SPI
GPC0: 5 in/out port – I2S, PCM, AC97
GPC1: 5 in/out port – I2S, SPDIF, LCD_FRM
1.1-11
