S5PV210AA0-LA40
y
y
Decoding support Main Profile High level
Decoding support MPEG-1 except D-picture
♦
SMPTE 421M VC-1
Decoding support Simple Profile Medium Level / Main Profile High Level / Advanced Profile Level4
y
•
JPEG Codec
♦
♦
Compression/decompression up to 65536x65536.
Support format of compression
* Input raw image: YCbCr4:2:2 or RGB565
* Output JPEG file: Baseline JPEG of YCbCr4:2:2 or YCbCr4:2:0
♦
♦
Support format of decompression (Refer to chapter 9.4)
* Input JPEG file: Baseline JPEG of YCbCr4:4:4, YCbCr4:2:2, YCbCr4:2:0, gray
* Output raw image: YCbCr4:2:2 or YCbCr4:2:0
Support general-purpose color-space converter.
•
3D Graphic Engine
♦
3D graphics, vector graphics and video encode and decode supported on common hardware
Tile based architecture
♦
♦
Universal Scalable Shader Engine – multi-threaded engine incorporating Pixel and Vertex Shader
functionality
♦
Advanced Shader Feature Set – in excess of Microsoft VS3.0, PS3.0 & OGL2.0
♦
♦
Industry standard API support – Direct3D Mobile, OGL-ES 1.1 and 2.0, OpenVG 1.0, OpenMax
Fine grained task switching, load balancing and power management
♦
♦
♦
Advanced geometry DMA driven operation for minimum CPU interaction
Programmable high quality image anti-aliasing
Fully virtualised memory addressing for OS operation in a unified memory architecture
•
•
Analog TV interface
Out video format: NTSC-M/NTSC-J/NTSC4.43/PAL-B, D, G, H, I/PAL-M/PAL-N/PAL-Nc/PAL-60
compliant
♦
♦
♦
♦
Support input format: ITU-R BT.601 (YCbCr 4 :4 :4)
Support 480i/p and 576i resolution
Support Composite/S-Video/Component interface
Digital TV Interface
♦
♦
♦
♦
High Definition Multimedia Interface (HDMI) 1.3
Support up to 1080p 60Hz and 8-channel/112kHz/24-bit audio
Support for 480p, 576p, 720p, 1080i (cannot support 480i)
Support for HDCP v1.1
1.1-7
SAMSUNG [ SAMSUNG ]
