S5PV210AA0-LA40
•
•
Rotator
♦
Supported image format: YCbCr422 (interleave), YCbCr420(non-interleave), RGB565 and
RGB888(unpacked)
♦
Supported rotate degree: 90, 180, 270, flip vertical and flip horizontal
Video processor
♦
♦
♦
♦
♦
♦
♦
♦
Support BOB / 2D-IPC mode
Produce YCbCr 4:4:4 outputs to help MIXER to blend video and graphics
1/4X to 16X vertical scaling with 4-tap/16-phase poly-phase filter
1/4X to 16X horizontal scaling with 8-tap/16-phase poly-phase filter
Support Pan&Scan, Letterbox, and NTSC/PAL conversion using scaling
Flexible scaled video positioning within display area
Support 1/16 pixel resolution Pan&Scan mode
Flexible post video processing
* Color saturation, Brightness/Contrast enhancement, Edge enhancement
* Color space conversion between BT.601 and BT.709
Video input source size upto 1920x1080
♦
•
•
Video Mixer
♦
♦
♦
Support overlapping & blending input video & graphic layers
Support 480i/p, 576i/p, 720p and 1080i/p display size
Support 4 layers (1 video layer, 2 graphic layer, 1 background layer)
TFT-LCD Interface
♦
♦
♦
♦
♦
♦
♦
♦
♦
♦
♦
Support 24/18/16-bpp parallel RGB Interface LCD
Support 8/6 bpp serial RGB Interface
Support Dual i80 Interface LCD
1/2/4/8bpp Palletized or 8/16/24-bpp Non-Palletized Color-TFT support
Typical actual screen size: 1024x768, 800x480, 640x480, 320x240, 160x160, and others
Virtual image up to 16M pixel (4K pixel x4K pixel)
Support 5 Window Layer for PIP or OSD
Real-time overlay plane multiplexing
Programmable OSD window positioning
16-level alpha blending
ITU-BT601/656 format output
1.1-8
