OneNAND512Mb(KFG1216U2B-xIB6)
FLASH MEMORY
3.0 DEVICE OPERATION
This section of the datasheet discusses the operation of the OneNAND device. It is followed by AC/DC
Characteristics and Timing Diagrams which may be consulted for further information.
The OneNAND supports a limited command-based interface in addition to a register-based interface for performing operations on the
device.
3.1
Command Based Operation
The command-based interface is active in the boot partition. Commands can only be written with a boot area address. Boot area data
is only returned if no command has been issued prior to the read.
The entire address range, except for the boot area, can be used for the data buffer. All commands are written to the boot partition.
Writes outside the boot partition are treated as normal writes to the buffers or registers.
The command consists of one or more cycles depending on the command. After completion of the command the device starts its exe-
cution. Writing incorrect information including address and data to the boot partition or writing an improper command will terminate
the previous command sequence and make the device enter the ready status.
The defined valid command sequences are stated in Command Sequences Table.
Command based operations are mainly used when OneNAND is used as Booting device, and all command based operations only
supports asynchronous reads and writes.
Command Sequences
Command Definition
Cycles
1st cycle
2nd cycle
BP1)
00F0h
BP
Add
Data
Add
Reset OneNAND
1
BP
Load Data into Buffer2)
2
2
0000h3)
XXXXh4)
Data
Data
Add
00E0h
BP
Read Identification Data 5)
Data
0090h
NOTE:
1) BP(Boot Partition) : BootRAM Area [0000h ~ 01FFh, 8000h ~ 800Fh].
2) Load Data into Buffer operation is available within a block(128KB)
3) Load 2KB unit into DataRAM0. Current Start address(FPA) is automatically incremented by 2KB unit after the load.
4) 0000h -> Data is Manufacturer ID
0001h -> Data is Device ID
0002h -> Current Block Write Protection Status for mono chip
5) WE toggling can terminate ’Read Identification Data’ operation.
