OneNAND512Mb(KFG1216U2B-xIB6)
FLASH MEMORY
Burst Length (BL)
Hosts must follow burst length set by BL when reading data in synchronous burst read.
BL
000
Burst Length(Main)
Burst Length(Spare)
Continuous(default)
4 words
001
010
8 words
011
16 words
100
32 words
N/A
101~111
Reserved
Note 1) For normal synchronous burst read, setting BL=000 (continuous) will read 1K words depending on the number of clocks.
Burst Length (BL) Information[11:9]
Item
Definition
Description
Specifies the size of the burst length during a synchronous
linear burst read and wrap around.
BL
Burst Length
Error Correction Code (ECC) Information[8]
Item
Definition
Description
0 = with correction (default)
1 = without correction (bypassed)
ECC
Error Correction Code Operation
RDY Polarity (RDYpol) Information[7]
Item
Definition
Description
1 = high for ready (default)
0 = low for ready
RDYpol
RDY signal polarity
INT Polarity (INTpol) Information[6]
INTpol
INT bit of Interrupt Status Register
INT Pin output
0 (busy)
1 (ready)
0 (busy)
1 (ready)
High
Low
Low
High
0
1 (default)
42
