OneNAND512Mb(KFG1216U2B-xIB6)
2.5 Block Diagram
FLASH MEMORY
BufferRAM
1st Block OTP
(Block 0)
Bootloader
DQ15~DQ0
A15~A0
CLK
BootRAM
StateMachine
DataRAM0
DataRAM1
CE
OE
NAND Flash
Array
WE
RP
Error
Correction
Logic
AVD
INT
Internal Registers
(Address/Command/Configuration
/Status Registers)
OTP
RDY
(One Block)
2.6
Memory Array Organization
The OneNAND architecture integrates several memory areas on a single chip.
2.6.1
Internal (NAND Array) Memory Organization
The on-chip internal memory is a single-level-cell (SLC) NAND array used for data storage and code. The internal memory is divided
into a main area and a spare area.
Main Area
The main area is the primary memory array. This main area is divided into Blocks of 64 Pages. Within a Block, each Page is 2KB and
is comprised of 4 Sectors. Within a Page, each Sector is 512B and is comprised of 256 Words.
Spare Area
The spare area is used for invalid block information and ECC storage. Spare area internal memory is associated with corresponding
main area memory. Within a Block, each Page has four 16B Sectors of spare area. Each spare area Sector is 8 words.
12
