K9K1208Q0C
K9K1208D0C
K9K1208U0C
K9K1216Q0C
K9K1216D0C
K9K1216U0C
FLASH MEMORY
READ ID
The device contains a product identification mode, initiated by writing 90h to the command register, followed by an address input of
00h. Two read cycles sequentially output the manufacture code(ECh), and the device code respectively. The command register
remains in Read ID mode until further commands are issued to it. Figure 13 shows the operation sequence.
Figure 13. Read ID Operation
CLE
tCEA
CE
WE
tAR
ALE
RE
tWHR1
tREA
Device
Code*
I/Ox
ECh
00h
90h
Address. 1cycle
Maker code
Device code
Device
Device Code*
K9K1208Q0C
36h
76h
K9K1208D0C
K9K1208U0C
K9K1216Q0C
76h
XX46h
K9K1216D0C
K9K1216U0C
XX56h
XX56h
RESET
The device offers a reset feature, executed by writing FFh to the command register. When the device is in Busy state during random
read, program or erase mode, the reset operation will abort these operations. The contents of memory cells being altered are no
longer valid, as the data will be partially programmed or erased. The command register is cleared to wait for the next command, and
the Status Register is cleared to value C0h when WP is high. Refer to table 5 for device status after reset operation. If the device is
already in reset state a new reset command will not be accepted by the command register. The R/B pin transitions to low for tRST
after the Reset command is written. Refer to Figure 14 below.
Figure 14. RESET Operation
tRST
R/B
I/Ox
FFh
Table5. Device Status
After Power-up
After Reset
Operation Mode
Read 1
Waiting for next command
31
