K9F5608Q0C
K9F5608D0C
K9F5608U0C
K9F5616Q0C
K9F5616D0C
K9F5616U0C
FLASH MEMORY
VALID BLOCK
Parameter
Symbol
Min
Typ.
Max
Unit
Valid Block Number
NVB
2013
-
2048
Blocks
NOTE :
1. The device may include invalid blocks when first shipped. Additional invalid blocks may develop while being used. The number of valid blocks is pre-
sented with both cases of invalid blocks considered. Invalid blocks are defined as blocks that contain one or more bad bits. Do not erase or program
factory-marked bad blocks. Refer to the attached technical notes for a appropriate management of invalid blocks.
2. The 1st block, which is placed on 00h block address, is guaranteed to be a valid block, does not require Error Correction up to 1K Program/Erase
cycles.
3. Minimum 1004 valid blocks are guaranteed for each contiguous 128Mb memory space.
AC TEST CONDITION
(K9F56XXX0C-XCB0 :TA=0 to 70°C, K9F56XXX0C-XIB0:TA=-40 to 85°C
K9F56XXQ0C : Vcc=1.70V~1.95V , K9F56XXD0C : Vcc=2.4V~2.9V , K9F56XXU0C : Vcc=2.7V~3.6V unless otherwise noted)
Parameter
K9F56XXQ0C
0V to VccQ
5ns
K9F56XXD0C
0V to VccQ
5ns
K9F56XXU0C
0.4V to 2.4V
5ns
Input Pulse Levels
Input Rise and Fall Times
Input and Output Timing Levels
VccQ/2
VccQ/2
1.5V
K9F56XXQ0C:Output Load (VccQ:1.8V +/-10%)
K9F56XXD0C:Output Load (VccQ:2.65V +/-10%) 1 TTL GATE and CL=30pF1 TTL GATE and CL=30pF 1 TTL GATE and CL=50pF
K9F56XXU0C:Output Load (VccQ:3.0V +/-10%)
K9F56XXU0C:Output Load (VccQ:3.3V +/-10%)
-
-
1 TTL GATE and CL=100pF
CAPACITANCE(TA=25°C, VCC=1.8V/2.65V/3.3V, f=1.0MHz)
Item
Symbol
Test Condition
Min
Max
Unit
pF
Input/Output Capacitance
Input Capacitance
CI/O
VIL=0V
-
-
10
10
CIN
VIN=0V
pF
NOTE : Capacitance is periodically sampled and not 100% tested.
MODE SELECTION
CLE
H
L
ALE
L
CE
L
WE
RE
H
LOCKPRE
WP
X
Mode
X
X
X
X
X
X
X
Command Input
Read Mode
H
L
L
H
X
Address Input(3clock)
Command Input
H
L
L
H
H
Write Mode
H
L
L
H
H
Address Input(3clock)
L
L
H
H
Data Input
Data Output
L
L
L
H
H
X
L
L
L
H
H
X
During Read(Busy) On K9F5608U0C_Y,P,V,F or K9F5608D0C_Y,P
During Read(Busy) on the devices except On
K9F5608U0C_Y,P,V,F or K9F5608D0C_Y,P
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
H
X
X
X
X
X
X
X
X
X
X
X
H
During Program(Busy)
During Erase(Busy)
Write Protect
H
L
X(1)
X
(2)
(2)
Stand-by
0V/VCC
0V/VCC
NOTE : 1. X can be VIL or VIH.
2. WP should be biased to CMOS high or CMOS low for standby.
13
