RT6343
Outline Dimension
H
A
Y
M
EXPOSED THERMAL PAD
(Bottom of Package)
J
B
X
F
C
I
D
Dimensions In Millimeters Dimensions In Inches
Symbol
Min
Max
Min
Max
A
B
C
D
F
H
I
4.801
3.810
1.346
0.330
1.194
0.170
0.000
5.791
0.406
2.000
2.000
2.100
3.000
5.004
4.000
1.753
0.510
1.346
0.254
0.152
6.200
1.270
2.300
2.300
2.500
3.500
0.189
0.150
0.053
0.013
0.047
0.007
0.000
0.228
0.016
0.079
0.079
0.083
0.118
0.197
0.157
0.069
0.020
0.053
0.010
0.006
0.244
0.050
0.091
0.091
0.098
0.138
J
M
X
Y
X
Y
Option 1
Option 2
8-Lead SOP (Exposed Pad) Plastic Package
Copyright 2019 Richtek Technology Corporation. All rights reserved.
©
is a registered trademark of Richtek Technology Corporation.
www.richtek.com
32
DS6343-00 October 2019
