MITSUBISHI MICROCOMPUTERS
M37754M8C-XXXGP, M37754M8C-XXXHP
M37754S4CGP, M37754S4CHP
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
(when 3-φ access in low-speed running <Read>)
tw(H) tw(L)
tr
tf
tc
f(XIN)
tw(φL)
φ1
tw(φH)
td(φ1-RD)
td(φ1-RD)
RD
tw(RD)
WR
tw(ALE)
td(ALE-RD)
ALE output
BHE output
td(BHE-RD)
th(RD-BHE)
td(BHE-ALE)
td(A-RD)
th(RD-A)
A0—A7 output
A8—A15 output
A16—A23 output
Address
td(A-ALE)
td(CS-RD)
th(RD-CS)
Chip select
CS0—CS4 output
td(CS-ALE)
ttssuu((CCSS--DDLL/D/DHH))
ttssuu((AA--DDLL/D/DHH))
tsu(DL/DH-RD)
Input data
th(RD-DL/DH)
D0—D7 input
D8—D15 input (BYTE = “L”)
td(LA-RD)
tpxz(RD-DLZ)
tpzx(RD-DLZ)
LA0—LA7 output
(D0/LA0—D7/LA7)
(multiplex bus (Note))
Address
td(LA-ALE)
tsu(DL-RD)
th(ALE-LA)
th(RD-DL)
tsu(LA-DL)
D0—D7 input
(multiplex bus (Note))
Data
tsu(PiD-RD)
th(RD-PiD)
Input data
Port Pi input
Note: These become a multiplex bus only when all of the following conditions are satisfied:
• BYTE = “H”
• Multiplex bus select bit = “1”
• While the address which corresponds to chip select signal CS4 is accessed
Test conditions (Port Pi, f(XIN))
• VCC = 5 V±10 %
Test conditions (except Port Pi, f(XIN))
• VCC = 5 V±10 %
• Input timing voltage : VIL = 1.0 V, VIH = 4.0 V
• Output timing voltage : VOL = 0.8 V, VOH = 2.0 V, CL = 100 pF
• Output timing voltage : VOL = 0.8 V, VOH = 2.0 V, CL = 100 pF
• Data input : VIL = 0.8 V, VIH = 2.5 V
