FM25L16B - 16Kb 3V SPI F-RAM
Mechanical Drawing
8-pin SOIC (JEDEC Standard MS-012, variation AA)
Recommended PCB Footprint
7.70
3.70
3.90
±
0.10 6.00 ±0.20
2.00
Pin 1
0.65
1.27
0.25
0.50
4.90 ±0.10
1.35
1.75
0.19
0.25
°
45
0.10 mm
1.27
0.10
0.25
0°- 8°
0.40
1.27
0.33
0.51
Refer to JEDEC MS-012 for complete dimensions and notes.
All dimensions in millimeters.
SOIC Package Marking Scheme
Legend:
XXXXXX= part number, P= package type (G=SOIC)
R=rev code, LLLLLLL= lot code
RIC=Ramtron Int’l Corp, YY=year, WW=work week
XXXXXXX-P
RLLLLLLL
RICYYWW
Example: FM25L16B, “Green” SOIC package, Year 2010, Work Week 47
FM25L16B-G
A00002G1
RIC1047
Rev. 1.3
Mar. 2011
