FM24CL16B - 16Kb 3V I2C F-RAM

Electrical Specifications

Absolute Maximum Ratings

Symbol

Description

V

DD

Power Supply Voltage with respect to V

SS

V

IN

Voltage on any pin with respect to V

SS

T

STG

T

LEAD

V

ESD

Storage Temperature

Lead temperature (Soldering, 10 seconds)

Electrostatic Discharge Voltage

- Human Body Model

(AEC-Q100-002 Rev. E)

- Charged Device Model

(AEC-Q100-011 Rev. B)

- Machine Model

(AEC-Q100-003 Rev. E)

Package Moisture Sensitivity Level

Ratings

-1.0V to +5.0V

-1.0V to +5.0V

and V

IN

< V

DD

+1.0V *

-55°C to + 125°C

260° C

4kV

1.25kV

300V

MSL-1

* Exception: The “V

IN

< V

DD

+1.0V” restriction does not apply to the SCL and SDA inputs.

Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating

only, and the functional operation of the device at these or any other conditions above those listed in the operational section of this

specification is not implied. Exposure to absolute maximum ratings conditions for extended periods may affect device reliability.

DC Operating Conditions

(T

A

= -40° C to + 85° C, V

DD

=2.7V to 3.65V unless otherwise specified)

Symbol

Parameter

Min

Typ

Max

Units

V

DD

Main Power Supply

2.7

3.3

3.65

V

I

DD

VDD Supply Current

100

@ SCL = 100 kHz

µA

170

@ SCL = 400 kHz

µA

300

@ SCL = 1 MHz

µA

I

SB

Standby Current

3

6

µA

I

LI

Input Leakage Current

±1

µA

I

LO

Output Leakage Current

±1

µA

V

IH

Input High Voltage

0.7 V

DD

V

DD

+ 0.3

V

V

IL

Input Low Voltage

-0.3

0.3 V

DD

V

V

OL

Output Low Voltage

@ I

OL

= 3.0 mA

0.4

V

R

IN

WP Input Resistance (WP)

For V

IN

= V

IL

(max)

40

KΩ

For V

IN

= V

IH

(min)

1

MΩ

V

HYS

Input Hysteresis

(Does not apply to WP)

0.05 V

DD

V

Notes

1

2

3

3

5

4

Notes

1. SCL toggling between V

DD

-0.3V and V

SS

, other inputs V

SS

or V

DD

-0.3V.

2. SCL = SDA = V

DD

. All inputs V

SS

or V

DD

. Stop command issued.

3. V

IN

or V

OUT

= V

SS

to V

DD

. Does not apply to the WP pin.

4. This parameter is characterized but not tested.

5. The input pull-down circuit is strong (40KΩ) when the input voltage is below V

IL

and much weaker (1MΩ)

when the input voltage is above V

IH

.

Rev. 1.4

Feb. 2011

Page 8 of 13
