QN8007B/8007LB
Word: RDSFDEV Address: 18h
Bit 7
(MSB)
Bit 0
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
(LSB)
rdsfdev[0]
wo
rsvd
rdsfdev[6]
wo
rdsfdev[5]
wo
rdsfdev[4]
wo
rdsfdev[3]
wo
rdsfdev[2]
wo
rdsfdev[1]
wo
wo
Bit
Symbol
rsvd
6:0 RDSFDEV[6:0] 000 0110 Specify RDS frequency deviation:
RDS frequency deviation = 0.35 kHz*RDSFDEV.
RDSFDEV[6:0] Value
000 0000 - 111 1111 0 ~ 127
Default
Description
7
1
Reserved
Word: CCA Address: 19h
Bit 7
Bit 0
(LSB)
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
(MSB)
txccaa[2]
wo
txccaa[1]
wo
txccaa[0]
wo
rsvd
wo
rsvd
wo
rsvd
wo
rsvd
wo
rsvd
wo
Bit
Symbol
TXCCAA[2:0]
Default
Description
7:5
010
Scaling factor to determine in-band noise power to out of band noise power
ratio. Value 0 ~ 7 directly written in, default is 2. When TXCCAA is not zero,
valid channels must satisfy the condition "in-band power > TXCCAA * out-of-
band power", which usually is set to select channels without adjacent channel
interference. When TXCCAA=0, this condition is omitted.
4:0
rsvd
0 1001
Reserved
Rev 2.09 (11/09)
Confidential A
Copyright ©2009 by Quintic Corporation
Confidential Information contained herein is covered under Non-Disclosure Agreement (NDA).
Page 39
