November 2006
rev 1.5
ASM5P2308A
Operating Conditions for ASM5I2308A Industrial Temperature Devices
Parameter
Description
Min
Max
Unit
VDD
TA
Supply Voltage
3.0
-40
3.6
85
30
15
7
V
Operating Temperature (Ambient Temperature)
Load Capacitance, below 100MHz
Load Capacitance, from 100MHz to 133MHz
Input Capacitance
°C
pF
pF
pF
CL
CL
CIN
Electrical Characteristics for ASM5I2308A Industrial Temperature Devices
Parameter
Description
Test Conditions
Min
Max
Unit
VIL
VIH
IIL
Input LOW Voltage
Input HIGH Voltage
Input LOW Current
Input HIGH Current
0.8
V
V
2.0
VIN = 0V
50.0
µA
µA
IIH
VIN = VDD
100.0
IOL = 8mA (-1, -2)
IOH = 12mA (-1H, -5H)
VOL
Output LOW Voltage
Output HIGH Voltage
0.4
V
V
IOL = -8mA (-1, -2)
IOH = -12mA (-1H, -5H)
VOH
2.4
(-2,-3,-4)
(-1H,-5H)
49
60
34
18
Unloaded outputs 100MHz REF,
Select inputs at VDD or GND
IDD
Supply Current10
mA
Unloaded outputs, 66MHz REF
Unloaded outputs, 33MHz REF
(-1, -2, -3, -4)
(-1, -2, -3, -4)
Note:
10. Supply Currents are measured for PLL-Bypass Mode (S2=1, S1=0).
3.3V Zero Delay Buffer
16 of 16
Notice: The information in this document is subject to change without notice.
PULSECORE [ PulseCore Semiconductor ]
