PE43704
Product Specification
Typical Performance Data, 1 dB Step @ 25°C and VDD = 3.4V unless otherwise specified
Figure 15. 1 dB Step Attenuation vs. Frequency*
1
0.2GHz
0.9GHz
0.5
1.8GHz
2.2GHz
0
‐0.5
‐1
3GHz
4GHz
5GHz
6GHz
7GHz
8GHz
0
4
8
12
16
20
24
28
32
Attenuation Setting (dB)
* Monotonicity is held so long as step-attenuation does not cross below –1.0 dB
Figure 16. 1 dB Step, Actual vs. Frequency
35
30
0.9GHz
25
20
15
10
5
2.2GHz
3GHz
4GHz
5GHz
6GHz
7GHz
8GHz
0
0
4
8
12
16
20
24
28
32
Ideal Attenuation (dB)
Figure 17. 1 dB Major State Bit Error vs.
Attenuation Setting
1.5
1
1dB
2dB
0.5
0
4dB
8dB
16dB
31dB
‐0.5
‐1
0
1
2
3
4
5
6
7
8
Frequency (GHz)
Document No. DOC-16514-6 |
www.psemi.com
©2012-2013 Peregrine Semiconductor Corp. All rights reserved.
Page 13 of 20
Logo updated under non-rev change. Peregrine products are protected under one or more of the following U.S. Patents: http://patents.psemi.com
