S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x0E6, 0x1E6, 0x2E6, 0x3E6, 0x4E6, 0x5E6, 0x6E6, 0x7E6:
RASE SF Saturation Threshold LSB
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
SFSTH[7]
SFSTH[6]
SFSTH[5]
SFSTH[4]
SFSTH[3]
SFSTH[2]
SFSTH[1]
SFSTH[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
0
0
0
0
0
0
Register 0x0E7, 0x1E7, 0x2E7, 0x3E7, 0x4E7, 0x5E7, 0x6E7, 0x7E7:
RASE SF Saturation Threshold MSB
Bit
Type
Function
Unused
Unused
Unused
Unused
SFSTH[11]
SFSTH[10]
SFSTH[9]
SFSTH[8]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
X
X
X
0
0
0
0
R/W
R/W
R/W
R/W
SFSTH[11:0]:
The SFSTH[11:0] value represents the allowable number of B2 errors that can be
accumulated during an evaluation window before an SF threshold event is declared. Setting
this threshold to 0xFFF disables the saturation functionality. Refer to the Operations
section for the recommended settings.
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
288
