Philips Semiconductors
Product specification
High speed CAN transceiver
TJA1041A
SYMBOL
th(min)
PARAMETER
CONDITIONS
MIN.
20
TYP.
MAX.
50
UNIT
minimum hold time of
go-to-sleep command
35
µs
tBUSdom
tBUSrec
twake
dominant time for wake-up
via bus
standby or sleep mode;
0.75
0.75
5
1.75
1.75
25
5
µs
µs
µs
VBAT = 12 V
recessive time for wake-up
via bus
standby or sleep mode;
VBAT = 12 V
5
minimum wake-up time after standby or sleep mode;
50
receiving a falling or rising
edge
VBAT = 12 V
Thermal shutdown
Tj(sd)
shutdown junction
temperature
155
165
180
°C
Note
1. All parameters are guaranteed over the virtual junction temperature range by design, but only 100 % tested at
amb = 125 °C for dies on wafer level and in addition to this, 100 % tested at Tamb = 125 °C for cased products, unless
T
specified otherwise. For bare dies, all parameters are only guaranteed with the reverse side of the die connected to
ground.
TEST AND APPLICATION INFORMATION
handbook, full pagewidth
3 V
5 V
BAT
V
V
V
I/O
INH
BAT
CC
V
CC
STB
EN
WAKE
GND
Port x, y, z
ERR
MICRO-
CONTROLLER
TJA1041A
RXD
TXD
RXD
TXD
CANH
CANL
SPLIT
MNB116
CAN bus wires
Fig.4 Typical application with 3 V microcontroller.
2004 Feb 20
15
