REGISTER ASSIGNMENT
SAD1 SAD2
(HEX) (HEX)
CONTROL
BIT
FUNCTION
TRACKS WITH
FUNCTION
Moire
cancellation via
vertical position
NAME
BITS
RANGE
D7 D6 D5 D4 D3 D2 D1 D0
VMOIRE
6
00
80
X
X
X
D5 D4 D3 D2 D1 D0
D5 D4 D3 D2 D1 D0
MOD
0 to 0.08% of
vertical amplitude
−
−
Moire
HMOIRE
VFOCUS
6
06
86
X
MOD
0.07% of horizontal
period
cancellation via
horizontal
position
Vertical focus
4
0E
8E
D7 D6 D5 D4
#
#
#
#
−
0 to 1.1 V
VSIZE, VOVSCN
and VPOS
Horizontal focus HFOCUS
5
2
0C
0C
8C
8C
#
#
X
X
D4 D3 D2 D1 D0
−
−
0 to 3.3 V
−
−
Horizontal focus HFOCAD
pre-correction
D7 D6
#
#
#
#
#
300 to 450 ns
Notes
1. X = don’t care.
2. # = this bit is occupied by another function. If the register is addressed, the bit values for both functions must be transferred.
