Absolute Maximum Ratings
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be
operable above the recommended operating conditions and stressing the parts to these levels is not recommended.
In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability.
The absolute maximum ratings are stress ratings only.
Symbol
VCC
Parameter
Min.
-0.5
-0.5
-0.5
-50
Max.
4.6
Unit
V
Supply Voltage
VS
DC Switch Voltage
DC Input Voltage(1)
VCC + 0.05
4.6
V
VIN
V
IIK
DC Input Diode Current, VIN<0V
DC Output Sink Current
mA
mA
mA
°C
IOUT
50
ICC / IGND
TSTG
DC VCC / GND Current
±100
-65
Storage Temperature Range
+150
All Pins
7000
7000
ESD
Human Body Model, JESD22-A114
V
I/O to GND
Note:
1. The input and output negative voltage ratings may be exceeded if the input and output diode current ratings are
observed.
Recommended Operating Conditions
The Recommended Operating Conditions table defines the conditions for actual device operation. Recommended
operating conditions are specified to ensure optimal performance to the datasheet specifications. Fairchild does not
recommend exceeding them or designing to Absolute Maximum Ratings.
Symbol
VCC
Parameter
Min.
3.0
0
Max.
3.6
Unit
V
Power Supply Operating
VIN
Input Voltage
VCC
VCC
5
V
VOUT
Output Voltage
0
V
Switch Control Input(2)
Switch I/O
0
tr, tf
Input Rise and Fall Time
ns/V
°C
0
DC
+85
TA
Operating Temperature, Free Air
-40
Note:
2. Unused control inputs must be held HIGH or LOW. They may not float.
© 2005 Fairchild Semiconductor Corporation
www.fairchildsemi.com
FSUSB20 • Rev. 1.0.3
