PSPICE Thermal Model
JUNCTION
th
REV 23 January 2004
FDD8876T
CTHERM1 TH 6 7e-4
CTHERM2 6 5 9e-4
CTHERM3 5 4 2e-3
CTHERM4 4 3 2.5e-3
CTHERM5 3 2 6e-3
CTHERM6 2 TL 1.1e-2
RTHERM1
RTHERM2
RTHERM3
RTHERM4
RTHERM5
RTHERM6
CTHERM1
6
RTHERM1 TH 6 7.0e-2
RTHERM2 6 5 1.1e-1
RTHERM3 5 4 2.2e-1
RTHERM4 4 3 3.2e-1
RTHERM5 3 2 4.9e-1
RTHERM6 2 TL 5e-1
CTHERM2
CTHERM3
CTHERM4
CTHERM5
CTHERM6
5
SABER Thermal Model
SABER thermal model FDD8876T
template thermal_model th tl
thermal_c th, tl
{
ctherm.ctherm1 th 6 =7e-4
ctherm.ctherm2 6 5 =9e-4
ctherm.ctherm3 5 4 =2e-3
ctherm.ctherm4 4 3 =2.5e-3
ctherm.ctherm5 3 2 =6e-3
ctherm.ctherm6 2 tl =1.1e-2
4
3
2
rtherm.rtherm1 th 6 =7.0e-2
rtherm.rtherm2 6 5 =1.1e-1
rtherm.rtherm3 5 4 =2.2e-1
rtherm.rtherm4 4 3 =3.2e-1
rtherm.rtherm5 3 2 =4.9e-1
rtherm.rtherm6 2 tl =5e-1
}
tl
CASE
©2008 Fairchild Semiconductor Corporation
FDD8876 / FDU8876 Rev. 1.2
