Tape and Reel Specifications
and Packaging Specifications
Embossed Tape and Reel is used to facilitate automatic pick and place equipment feed requirements. The tape is used as the
shipping container for various products and requires a minimum of handling. The antistatic/conductive tape provides a secure
cavity for the product when sealed with the “peel–back” cover tape.
• Two Reel Sizes Available (7″ and 13″)
• Used for Automatic Pick and Place Feed Systems
• Minimizes Product Handling
• EIA 481, –1, –2
• DPAK SO–14, in 16 mm Tape
2
• D PAK in 24 mm Tape
Usethestandarddevicetitleandaddtherequiredsuffixaslistedintheoptiontableonthefollowingpage. Notethattheindividual
reels have a finite number of devices depending on the type of product contained in the tape. Also note the minimum lot size is
one full reel for each line item, and orders are required to be in increments of the single reel quantity.
2
24
D PAK
DPAK
16
mm
mm
DIRECTION
OF FEED
Tape Width
(mm)
Reel Size
(inch)
Package
DPAK
16
24
8.0 ± 0.1 (.315 ± .004)
16.0 ± 0.1 (.630 ± .004)
330
330
(13)
(13)
2,500
800
T4
T4
2
D PAK
Surface Mount Package Information and Tape and Reel Specifications
4–6
Motorola Bipolar Power Transistor Device Data
