WL/WLM
According to Application Conditions
Conditions
Key specifications
Models
10 A at 125,250, or 500 VAC
0.8 A at 125 VDC
0.4 A at 250 VDC
WL@
WL@-S
WLM@
General-purpose Switches
Spatter-prevention Switches
Long-life Switches
Switching standard
loads
Switching
microloads
0.1 A at 125 VAC, resistive load
0.1 A at 30 VDC, resistive load
WL01@
General-purpose Microload Switches
WL01@-S Spatter-prevention Microload Switches
Mechanical: 15 million operation min.
(10 million operation min. for overtravel
general-purpose or high-sensitivity models or
flexible rod models)
WL@
General-purpose Switches
Spatter-prevention Switches
Normal durability
Long-life
WL@-S
Mechanical: 30 million operation min.
WLM@
Long-life Switches
According to Ease of Installation and Maintenance
Conditions
Key specifications
Models
Switching light-ON between operating/not
operating. (Switching not possible for models
with molded terminals.)
Neon lamp
125 to 250 VAC
WL@-LE
General-purpose, Indicator-equipped (Neon Lamp) Switches
WL@-LES
Spatter-prevention, Indicator-equipped (Neon Lamp) Switches
Daily inspections
and maintenance
checks
Switching light-ON between operating/not
operating. (Switching not possible for models
with molded terminals.)
WL@-LD
General-purpose, Indicator-equipped (LED) Switches
WL@-LDS
LED
Spatter-prevention, Indicator-equipped (LED) Switches
10 to 115 VAC/DC
Screw terminals. No ground terminal.
Conduit size: G1/2
WL@
General-purpose Switches
Long-life Switches
WLM@
Screw tightening
and installation
Screw terminals. Ground terminal.
Conduit size: 4 sizes
WL@
General-purpose Switches
WL@-@LDK13
Direct-wired connector, 2-conductor.
Greatly reduces wiring work.
Water-proof to IP67.
General-purpose, Direct-wired Connector Switches
WLM@-LDK13
One-touch
connector
attachment
Long-life, Direct-wired Connector Switches
WL@-@LDK43
Direct-wired connector, 4-conductor.
Greatly reduces wiring work.
Water-proof to IP67.
General-purpose, Direct-wired Connector Switches
WLM@-LDK43
Long-life, Direct-wired Connector Switches
WL@-@LD-M1J
General-purpose, Pre-wired Connector Switches
WL@-@S-M1J-1
Pre-wired connector, 2-conductor.
Greatly reduces wiring work.
Water-proof to IP67.
Spatter-prevention, Pre-wired Connector Switches
WLM@-LD-M1J
Connector
Long-life, Pre-wired Connector Switches
attachment in
control and relay
boxes
WL@-@LD-@GJO3
General-purpose, Pre-wired Connector Switches
WL@-@S-@GJSO3
Pre-wired connector, 4-conductor.
Greatly reduces wiring work.
Water-proof to IP67.
Spatter-prevention, Pre-wired Connector Switches
WLM@-LD-@GJO3
Long-life, Pre-wired Connector Switches
6
