WL/WLM
Direct-wired Connector
Pre-wired Connector
General-purpose Switches
Sensor I/O Connector Switches
WL @@-@ LD @
(1) (2) (3) (4) (5)
(1) Electrical Rating
(4) Indicator Type
Blank
01
Standard load
Microload
LD
LED, 10 to 115 VAC/DC
Note: Dimensions are the same as the standard models.
(5) Wiring Specifications
(2) Actuator Type
K13A
K13
K43A
K43
Direct-wired Connector (2-conductor: AC, NO wiring, connector pins No. 3, 4)
Direct-wired Connector (2-conductor: DC, NO wiring, connector pins No. 3, 4)
Direct-wired Connector (4-conductor: AC)
CA2
Roller lever: Standard model
GCA2
Roller lever: High-precision model
Roller lever: General-purpose
overtravel model
H2
G2
Direct-wired Connector (4-conductor: DC)
Roller-lever: High-sensitivity over-
travel model
-M1J *
Pre-wired Connector *2 (2-conductor: DC, NO wiring, connector pins No. 3, 4)
-M1GJ *1 Pre-wired Connector *2 (2-conductor: DC, NO wiring, connector pins No. 1, 4)
D2
Top-roller plunger
-M1JB
Pre-wired Connector *2 (2-conductor: DC, NC wiring, connector pins No. 3, 2)
Pre-wired Connector *2 (4-conductor, AC)
D28
Sealed top-roller plunger
-AGJ03
-DGJ03 *1 Pre-wired Connector *2 (4-conductor, DC)
(3) Built-in Switch Type
-DK1EJ03 *1 Pre-wired Connector *2 (3-conductor: DC, NO wiring, connector pins No. 2, 3, 4)
Blank
55
Standard
*1. Models with pre-wired connectors and DC specifications have EN/IEC approval (CE marking).
*2. With 0.3-m cable attached.
Hermetically sealed
Note: Dimensions are the same as the standard models.
Spatter-prevention Switches
Long-life Switches
WL @@-@@ S @
WLM@ -LD @
(1) (2) (3) (4)
(5)
(1) (2) (3)
(1) Electrical Rating
(1) Actuator
Blank
01
Standard load
Microload
CA2
GCA2
H2
Roller lever: Standard model
Roller lever: High-precision model
Roller lever: General-purpose overtravel model
Roller lever: High-sensitivity overtravel model
Note: Dimensions are the same as the standard models.
G2
(2) Actuator Type
CA2
GCA2
H2
Roller lever: Standard model
(2) Indicator Type
Roller lever: High-precision model
Roller lever: General-purpose Overtravel model
Roller lever: High-sensitivity Overtravel model
Sealed top-roller plunger
LD
LED, 10 to 115 VAC/DC
G2
D28
(3) Wiring Specifications
Blank
K13A
K13
Screw terminal: G1/2 conduit
Direct-wired Connector: 2-conductor, AC
Direct-wired Connector: 2-conductor, DC
Direct-wired Connector: 4-conductor, AC
Direct-wired Connector: 4-conductor, DC
Pre-wired Connector: 2-conductor, DC *
(3) Built-in Switch Type
Blank
55
Standard
K43A
K43
-M1J
Hermetically sealed
Note: Dimensions are the same as the standard models.
(4) Indicator Type
-AGJ03 Pre-wired Connector: 4-conductor, AC *
-DGJ03 Pre-wired Connector: 4-conductor, DC *
* With 0.3-m cable attached.
LD
LE
LED, AC/DC
Neon lamp
Note: Dimensions are the same for both LE and LD models.
(5) Wiring Specifications
Blank
Screw terminal: G1/2 conduit
Pre-wired Connector *2
(2-conductor: DC, NO wiring, connector pins No. 3, 4)
-M1J-1 *1
Pre-wired Connector *2
(2-conductor: DC, NO wiring, connector pins No. 1, 4)
-M1GJ-1 *1
-DGJS03 *1 Pre-wired Connector *2 (4-conductor: DC)
*1. Models with pre-wired connectors and DC specifications are approved by
EN/IEC (CE marking) except for LE Models (Neon Lamp Models).
*2. With 0.3-m cable attached.
10
