PEDL5501-02
OKI Semiconductor
ML5501
Absolute maximum rating
Parameter
Symbol
Conditions
Range
Units
Power Supply
Input Voltage
Output Voltage
Junction Temperature
Storage Temperature
VIN, VDD
Set, Sd
Vout
Tj
TSTG
-0.3 to 21
-0.3 to VDD + 0.3
-0.3 to VIN + 0.3
150
V
V
V
°C
°C
Ta=25degreeC
GND=0V
-
-
-65 to 150
Recommended Operating Conditions
Parameter
Min.
Typ.
Max.
Units
Power Supply Range（VDD）
10.8
12
13.2
V
Output Current
300
125
mA
°C
Operating Junction temperature
0
Electrical Specifications
Typicals and limits appearing in normal type apply for TJ = 25°C. Limits appearing in Boldface type apply over the entire junction
temperature range for operation, 0°C to 125°C.
Parameter
Conditions
Min.
Typ.
Max.
Units
Sd, Set Pin interface
Sd H level Input Voltage (VIH)
Sd L level Input Voltage (VIL)
Set H level Input Voltage (VIH)
Set L level Input Voltage (VIL)
H level Leak Current (IIH)
L level Leak Current (IIL)
2.7
V
V
V
V
uA
uA
0.4
0.9*Vdd
0.1*Vdd
5
Set, Sd = Vdd
Set, Sd = Gnd
- 5
Pok Pin interface (Open Drain)
Output Voltage (VOL)
IOL=2mA
0.4
V
Power Supply
Power Supply Range
10.8
13.2
V
Current consumption
（Normal）
SD=L, Output = Open
5
10
mA
Current consumption
（Shutdown）
SD=H, Output = Open,
Not Switching
100
uA
Rev 1.0
4 / 13
