FEDL2250DIGEST-01
OKI Semiconductor
ML2252/54-XXX, ML22Q54
Analog Section Characteristics (3 V)
ML2252/54-XXX, ML22Q54
ML2252/54-XXX: DVDD = AVDD = 2.7 to 3.6 V, DGND = AGND = 0 V, Ta = –40 to +85°C
ML22Q54: DVDD = AVDD = 2.7 to 3.6 V, DGND = AGND = 0 V, Ta = 0 to +70°C
Parameter
Symbol
Condition
Min.
Typ.
Max.
Unit
AOUT output load
resistance
RLAO
—
50
—
—
kΩ
AOUT output voltage range
DAO output impedance
VAOUT
RDAO
No output load
—
0.5
30
—
AVDD –0.5
60
V
43
kΩ
OUT(+), OUT(–) “H” level
output voltage
VPWMH
VPWML
IOH = –2 mA
IOH = 2 mA
AVDD –0.4
—
—
—
—
V
V
OUT(+), OUT(–) “L” level
output voltage
0.4
Analog output maximum
amplitude when PWM
output is selected.
20 kHz LPF used when
OPTANA pin = “H”.
VPWMO
—
—
AVDD × 0.5
VP-P
Analog Section Characteristics (5 V)
ML2252/54-XXX
DVDD = AVDD = 4.5 to 5.5 V, DGND = AGND = 0 V, Ta = –40 to +85°C
Parameter
Symbol
RLAO
Condition
Min.
Typ.
Max.
Unit
AOUT output load
resistance
—
50
—
—
kΩ
AOUT output voltage range
DAO output impedance
VAOUT
RDAO
No output load
—
0.5
30
—
AVDD –0.5
60
V
43
kΩ
OUT(+), OUT(–) “H” level
output voltage
VPWMH
VPWML
IOH = –2 mA
IOH = 2 mA
AVDD –0.4
—
—
—
—
V
V
OUT(+), OUT(–) “L” level
output voltage
0.4
Analog output maximum
amplitude when PWM
output is selected.
20 kHz LPF used when
OPTANA pin = “H”.
VPWMO
—
—
AVDD × 0.5
VP-P
16/31
