Philips Semiconductors
Product specication
I2C-bus controlled 4 45 Watt power
amplier and multiple voltage regulator
TDA8589J; TDA8589xJ
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 60134).
SYMBOL
VP
PARAMETER
supply voltage
CONDITION
MIN.
MAX.
18
50
UNIT
operating
V
V
V
V
V
not operating
with load dump protection
operating
1
0
0
0
50
7
VSDA, VSCL voltage on pins SDA and SCL
VIN, VSVR
VACGND
VDIAG
VSTB
IOSM
,
voltage on pins INn, SVR,
ACGND and DIAG
operating
13
,
voltage on pin STB
operating
0
24
10
V
A
non-repetitive peak output
current
IORM
Vsc
repetitive peak output current
6
A
V
AC and DC short-circuit voltage short-circuit of output pins across
loads and to ground or supply
18
Vrp
reverse polarity voltage
total power dissipation
junction temperature
storage temperature
ambient temperature
voltage regulator only
Tcase = 70 C
18
V
Ptot
Tj
80
W
150
C
Tstg
Tamb
Vesd
55
40
150
C
C
85
electrostatic discharge voltage note 1
note 2
2000
200
V
V
Notes
1. Human body model: Rs = 1.5 k ; C = 100 pF; all pins have passed all tests to 2500 V to guarantee 2000 V,
according to class II.
2. Machine model: Rs = 10 ; C = 200 pF; L = 0.75 mH; all pins have passed all tests to 250 V to guarantee 200 V,
according to class II.
2004 Feb 24
