Philips Semiconductors
Product specication
I2C-bus controlled 4 45 Watt power
amplier and multiple voltage regulator
TDA8589J; TDA8589xJ
Protection
Temperature protection
All regulator and switch outputs are fully protected by
foldback current limiting against load dumps and
short-circuits; see Fig.6. During a load dump all regulator
outputs, except the output of regulator 2, will go low.
If the junction temperature of a regulator becomes too
high, the amplifier(s) are switched off to prevent unwanted
noise signals being audible. A regulator junction
temperature that is too high is indicated by pin DIAG going
LOW and is also indicated by setting bit D6 in data byte 2.
The power switches can withstand ‘loss-of-ground’. This
means that if pin GND becomes disconnected, the switch
is protected by automatically connecting its outputs to
ground.
If the junction temperature of the regulator continues to
rise and reaches the maximum temperature protection
level, all regulators and switches will be disabled except
regulator 2.
V
O(REGn)
I
I
I
limit
O(REGn)
sc
Fig.6 Foldback current protection.
2004 Feb 24
13
