P5CD016/021/041/051 and P5Cx081
NXP Semiconductors
Secure dual interface and contact PKI smart card controller
2.4 Design-in support
Approved development tool chain:
Keil PK51 development tool package including μVision3/dScope C51 simulator,
additional specific hardware drivers including simulation of contactless interface
and ISO/IEC 7816 card interface board. A SmartMX DBox allows software
debugging and integration tests.
Ashling Ultra-Emulator platform, stand-alone ROM prototyping boards and
ISO/IEC 7816 and ISO/IEC 14443 card interface board. Code coverage and
performance measurement software tools for real-time software testing.
Dual interface dummy modules OM6711 (PDM 1.1 - SOT658) with special antenna
bonding on C4 and C8 for testing the implanting process and antenna connection.
Software libraries:
Libraries supporting contactless communication in accordance with
ISO/IEC 14443, part 3 and 4
T=1 communication in accordance with ISO/IEC 7816, part 3
EEPROM read/write routines
3. Applications
3.1 Application areas
Banking
Java cards
E-passports
ID cards
Secure access
Trusted platform modules
4. Quick reference data
Table 2.
Symbol
VDD
Quick reference data
Parameter
Conditions
Min
4.5
Typ
5.0
3.0
3.0
1.8
Max
5.5
Unit
V
[1]
[1]
[1]
[1]
supply voltage
class A: 5 V range
class B: 3 V range
class BE: 3 V range
Class C: 1.8 V range
2.7
3.3
V
2.2
3.3
V
1.62
1.98
V
EEPROM
tret
retention time
Tamb = +55 °C
25
5 × 105
-
-
-
-
years
Nendu(W)
write endurance
under all operating
conditions
cycles
[1] All described supply voltages are in accordance with ISO/IEC 7816-3.
P5CD016_021_041_51_Cx081_FAM_SDS
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product short data sheet
PUBLIC
Rev. 3.2 — 14 March 2011
150332
9 of 20
