LPC2210/2220
NXP Semiconductors
16/32-bit ARM microcontrollers
7. Limiting values
Table 10. Limiting values reset
In accordance with the Absolute Maximum Rating System (IEC 60134).[1]
Symbol
VDD(1V8)
VDD(3V3)
VDDA(3V3)
VIA
Parameter
Conditions
Min
−0.5
−0.5
−0.5
−0.5
−0.5
−0.5
-
Max
Unit
V
[2]
[3]
supply voltage (1.8 V)
supply voltage (3.3 V)
analog supply voltage (3.3 V)
analog input voltage
input voltage
+2.5
+3.6
V
+4.6
V
+5.1
V
[4][5]
[4][6]
[7][8]
[8][9]
[10]
VI
5 V tolerant I/O pins
other I/O pins
+6.0
V
VDD(3V3) + 0.5
100
V
IDD
supply current
mA
mA
°C
W
ISS
ground current
-
100
Tstg
storage temperature
−65
-
+150
1.5
Ptot(pack)
total power dissipation (per
package)
based on package heat
transfer, not device power
consumption
[11]
Vesd
electrostatic discharge voltage human body model
all pins
−2000
+2000
V
[1] The following applies to Table 10:
a) This product includes circuitry specifically designed for the protection of its internal devices from the damaging effects of excessive
static charge. Nonetheless, it is suggested that conventional precautions be taken to avoid applying greater than the rated maximum.
b) Parameters are valid over operating temperature range unless otherwise specified. All voltages are with respect to VSS unless
otherwise noted.
[2] Internal rail.
[3] External rail.
[4] Including voltage on outputs in 3-state mode.
[5] Only valid when the VDD(3V3) supply voltage is present.
[6] Not to exceed 4.6 V.
[7] Per supply pin.
[8] The peak current is limited to 25 times the corresponding maximum current.
[9] Per ground pin.
[10] Dependent on package type.
[11] Human body model: equivalent to discharging a 100 pF capacitor through a 1.5 kΩ series resistor.
LPC2210_2220_6
© NXP B.V. 2008. All rights reserved.
Product data sheet
Rev. 06 — 11 December 2008
32 of 50
