NXP Semiconductors
FXTH87E
FXTH87E, Family of Tire Pressure Monitor Sensors
19 Revision history
Table 170.ꢀRevision history
Document ID
Release date
20190204
Description
FXTH87ERM v.5.0
• Section 4.3: Revised as follows:
– Figure 5: Removed an asterisk next to C4 in the image and removed
two paragraphs embedded in the graphic.
– Revised the two paragraphs removed from Figure 5 and inserted the
paragraphs into the narrative of Section 4.3 following Figure 5.
– Inserted a note as the last paragraph of Section 4.3.
• Section 19: Revised the description for FXTH87ERM v.2.0 from
"Product data sheet" to "Product reference manual."
FXTH87ERM v.4.0
20181129
• Performed minor corrections throughout the narrative to conform with
NXP guidelines.
• Section 1.3 "Related documentation": Revised the steps providing a
direct link to the FXTH87E page on NXP.com.
• Section 2.2 "Features and benefits": Added "Optional XZ- or" before
the feature "Z-axis accelerometer with adjustable offset option".
• Section 2.4 "Part number definition": Added Section 2.4 to document
part numbering.
• Section 2.5 "Part marking definition": Added Section 2.5 to document
part marking.
• Section 3.1 "Overall block diagram": Revised the title from "Block
diagram" to "Overall block diagram".
• Section 4 "Pinning information": Added "This section describes the
pin layout and general function of each pin." as the first paragraph in
Section 4
• Section 4.3, Figure 5: Minor updates to text within the image and in
the paragraphs below the image.
• Section 16.2.2 "Device identification", Table 164: Revised the
description "special calibration for accelerometer" for "Field CODE1, 1"
as follows:
– Changed "0 = standard –240 to +270 g Z-axis" to "0 = standard -215
to +305 g Z-axis"
– Changed "1 = extended –270 to +400 g Z-axis" to "1 = extended
-285 to +400 g Z-axis"
FXTH87ERM
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2019. All rights reserved.
Reference manual
Rev. 5.0 — 4 February 2019
174 / 183
