FXTH87E, Family of Tire Pressure Monitor Sensors
Field
Description
Force/Tag Select — When FTS = 1, a breakpoint is requested whenever the CPU address bus matches
the BDCBKPT match register. When FTS = 0, a match between the CPU address bus and the BDCBKPT
register causes the fetched opcode to be tagged. If this tagged opcode ever reaches the end of the
instruction queue, the CPU enters ACTIVE BACKGROUND mode rather than executing the tagged opcode.
4
0ꢀTag opcode at breakpoint address and enter ACTIVE BACKGROUND mode if CPU attempts to execute
that instruction
FTS
1ꢀBreakpoint match forces ACTIVE BACKGROUND mode at next instruction boundary (address need not
be an opcode)
Select Source for BDC Communications Clock — CLKSW defaults to 0, which selects the alternate BDC
clock source.
3
0ꢀAlternate BDC clock source
1ꢀMCU bus clock
CLKSW
WAIT or STOP Status — When the target CPU is in WAIT or STOP mode, most BDC commands cannot
function. However, the BACKGROUND command can be used to force the target CPU out of WAIT or STOP
and into ACTIVE BACKGROUND mode where all BDC commands work. Whenever the host forces the
target MCU into ACTIVE BACKGROUND mode, the host should issue a READ_STATUS command to check
that BDMACT = 1 before attempting other BDC commands.
2
WS
0ꢀTarget CPU is running user application code or in ACTIVE BACKGROUND mode (was not in WAIT or
STOP mode when BACKGROUND became active)
1ꢀTarget CPU is in WAIT or STOP mode, or a BACKGROUND command was used to change from WAIT or
STOP to ACTIVE BACKGROUND mode
WAIT or STOP Failure Status — This status bit is set if a memory access command failed due to the target
CPU executing a WAIT or STOP instruction at or about the same time. The usual recovery strategy is to
issue a BACKGROUND command to get out of WAIT or STOP mode into ACTIVE BACKGROUND mode,
repeat the command that failed, then return to the user program. (Typically, the host would restore CPU
registers and stack values and re-execute the WAIT or STOP instruction.)
1
WSF
0ꢀMemory access did not conflict with a WAIT or STOP instruction
1ꢀMemory access command failed because the CPU entered WAIT or STOP mode
Data Valid Failure Status — This status bit is not used in the MC9S08RA16 because it does not have any
slow access memory.
0
0ꢀMemory access did not conflict with a slow memory access
DVF
1ꢀMemory access command failed because CPU was not finished with a slow memory access
17.3.3 BDC breakpoint match register (BDCBKPT)
This 16-bit register holds the address for the hardware breakpoint in the BDC. The
BKPTEN and FTS control bits in BDCSCR are used to enable and configure the
breakpoint logic. Dedicated serial BDC commands (READ_BKPT and WRITE_BKPT)
are used to read and write the BDCBKPT register but is not accessible to user programs
because it is not located in the normal memory map of the MCU. Breakpoints are
normally set while the target MCU is in ACTIVE BACKGROUND mode before running
the user application program. For additional information about setup and use of
the hardware breakpoint logic in the BDC, refer to Section 17.2.4 "BDC hardware
breakpoint".
17.3.4 System background debug force reset register (SBDFR)
This register contains a single write-only control bit. A serial BACKGROUND mode
command such as WRITE_BYTE must be used to write to SBDFR. Attempts to write this
register from a user program are ignored. Reads always return 0x00.
