M25PX64
DC and AC parameters
Table 16. DC characteristics
Test condition (in addition
Symbol
Parameter
Min
Max
Unit
to those in Table 13)
ICC1
ICC2
Standby current
S = VCC, VIN = VSS or VCC
S = VCC, VIN = VSS or VCC
50
10
μA
μA
Deep Power-down current
Operating current (READ)
C = 0.1VCC / 0.9VCC at
75 MHz, DQ1 = open
12
4
mA
mA
mA
C = 0.1VCC / 0.9VCC at
33 MHz, DQ1 = open
ICC3
C = 0.1VCC / 0.9VCC at
75 MHz, DQ1 = open
Operating current (DOFR)
15
Operating current (PP)
Operating current (DIFP)
Operating current (WRSR)
Operating current (SE)
S = VCC
S = VCC
S = VCC
S = VCC
15
15
15
15
mA
mA
mA
mA
ICC4
ICC5
ICC6
VPP operating current in fast
bulk erase mode
IPP
S = VCC, VPP = VPPH
20
mA
VIL
VIH
Input low voltage
Input high voltage
Output low voltage
Output high voltage
– 0.5
0.3VCC
V
V
V
V
0.7VCC VCC+0.4
VOL
VOH
IOL = 1.6 mA
0.4
IOH = –100 μA
VCC–0.2
