DC and AC parameters
This section summarizes the operating and measurement conditions, and the DC and AC
characteristics of the device. The parameters in the DC and AC characteristics tables that
follow are derived from tests performed under the measurement conditions summarized in
the relevant tables. Designers should check that the operating conditions in their circuit
match the measurement conditions when relying on the quoted parameters.
Table 13. Operating conditions
Symbol
Parameter
Min
Typ
Max
Unit
VCC
VPPH
TA
Supply voltage
2.7
8.5
–40
3.6
9.5
85
V
V
Supply voltage on VPP
Ambient operating temperature
°C
Table 14. AC measurement conditions
Symbol
Parameter
Min
Max
Unit
CL
Load capacitance
30
pF
ns
V
Input rise and fall times
5
Input pulse voltages
0.2VCC to 0.8VCC
0.3VCC to 0.7VCC
VCC / 2
Input timing reference voltages
Output timing reference voltages
V
V
Figure 29. AC measurement I/O waveform
Input levels
Input and output
timing reference levels
0.8V
CC
0.7V
CC
CC
0.3V
CC
0.5V
0.2V
CC
AI07455
Table 15. Capacitance(1)
Symbol
Parameter
Test condition
Min
Max
Unit
CIN/OUT Input/output capacitance (DQ0/DQ1)
CIN Input capacitance (other pins)
VOUT = 0 V
VIN = 0 V
8
6
pF
pF
1. Sampled only, not 100% tested, at TA=25 °C and a frequency of 33 MHz.
Table 16. DC characteristics
Test condition (in addition
Symbol
Parameter
Min
Max
Unit
to those in Table 13)
ILI
Input leakage current
Output leakage current
± 2
± 2
μA
μA
ILO
