XC7SH86
2-input EXCLUSIVE-OR gate
8. Limiting values
Table 5. Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134). Voltages are referenced to GND (ground = 0 V).
Symbol Parameter
Conditions
Min
-0.5
-0.5
-20
-
Max
+7.0
+7.0
-
Unit
V
VCC
VI
supply voltage
input voltage
V
IIK
input clamping current
output clamping current
output current
VI < -0.5 V
mA
mA
mA
mA
mA
°C
IOK
IO
VO < -0.5 V or VO > VCC + 0.5 V
-0.5 V < VO < VCC + 0.5 V
[1]
[2]
±20
±25
75
-
ICC
IGND
Tstg
Ptot
supply current
-
ground current
-75
-65
-
-
storage temperature
total power dissipation
+150
250
Tamb = -40 °C to +125 °C
mW
[1] The input and output voltage ratings may be exceeded if the input and output current ratings are observed.
[2] For SOT353-1 (TSSOP5) package: Ptot derates linearly with 3.3 mW/K above 74 °C.
For SOT753 (SC-74A) package: Ptot derates linearly with 3.8 mW/K above 85 °C.
9. Recommended operating conditions
Table 6. Recommended operating conditions
Voltages are referenced to GND (ground = 0 V).
Symbol Parameter
Conditions
Min
2.0
0
Typ
Max
5.5
Unit
V
VCC
VI
supply voltage
5.0
input voltage
-
5.5
V
VO
output voltage
0
-
VCC
+125
100
20
V
Tamb
Δt/ΔV
ambient temperature
input transition rise and fall rate
-40
-
+25
°C
VCC = 3.3 V ± 0.3 V
VCC = 5.0 V ± 0.5 V
-
-
ns/V
ns/V
-
©
