Nexperia
PRTR5V0U2X-Q
Ultra low capacitance double rail-to-rail ESD protection diode
12. Soldering
3.25
1.9
0.6
(3×)
0.5
(3×)
solder lands
solder resist
0.7 0.6
(3×) (3×)
solder paste
2
3
occupied area
0.7 0.6
Dimensions in mm
0.75
0.95
0.9
1
sot143b_fr
Fig. 7. Reflow soldering footprint for SOT143B
4.45
2.2
1.2
(3×)
1.425
(3×)
solder lands
solder resist
occupied area
2.575
4.6
Dimensions in mm
1.425
preferred transport direction during soldering
1
1.2
sot143b_fw
Fig. 8. Wave soldering footprint for SOT143B
©
