Nexperia
PRTR5V0U2X-Q
Ultra low capacitance double rail-to-rail ESD protection diode
ESD TESTER
4 GHz DIGITAL
RG 223/U
50 Ω coax
OSCILLOSCOPE
50 Ω
R
Z
450 Ω
10×
ATTENUATOR
C
Z
DUT
Device
Under
Test
IEC 61000-4-2 network
= 150 pF; R = 330 Ω
C
Z
Z
vertical scale = 200 V/div
horizontal scale = 50 ns/div
vertical scale = 10 V/div
horizontal scale = 50 ns/div
GND
GND
unclamped +1 kV ESD voltage waveform
(IEC 61000-4-2 network)
clamped +1 kV ESD voltage waveform
(IEC 61000-4-2 network)
vertical scale = 10 V/div
horizontal scale = 50 ns/div
GND
GND
vertical scale = 200 V/div
horizontal scale = 50 ns/div
unclamped - 1 kV ESD voltage waveform
(IEC 61000-4-2 network)
clamped - 1 kV ESD voltage waveform
(IEC 61000-4-2 network)
006aab112
Fig. 4. ESD clamping test setup and waveforms
©
PRTR5V0U2X-Q
All information provided in this document is subject to legal disclaimers.
Nexperia B.V. 2022. All rights reserved
Product data sheet
4 May 2022
5 / 11
