10. MASK OPTION SELECTION
The µPD75216A has the following mask options enabling or disabling on-chip components.
(1) Pin
Pin
Mask Option
Pull-up resistor incorporation enabled bit-wise
P60 to P63
T0/T9
T10/S15/PH3 to T13/S12/PH0
T14/S11, T15/S10
S0 to S9
XT1, XT2
Deletion of subsystem clock oscillator feedback resistor
possible
Note 1. In a system not using subsystem clocks, power consumption in the STOP mode can be decreased by
removing the feedback resistor from the oscillator.
2. The feedback resistor must be incorporated when using subsystem clock.
(2) Power-on reset generator, power-on flag (PONF)
One of the following three can be selected.
Switch Selection
(See Fig. 8-1)
Power-On Flag (PONF)
Internal Reset Signal (RES)
Power-On Reset Generator
SWA
ON
SWB
ON
Incorporated
Incorporated
Generate automatically
Not generate automatically
–––––
Incorporated
Incorporated
ON
OFF
OFF
Not incorporated
Not incorporated
OFF
