µPD703100A-33, 703100A-40, 703101A-33, 703102A-33
(3/3)
Pin Name
P120
I/O
I/O
Function
Alternate Function
Port 12
TO150
TO151
TCLR15
TI15
8-bit I/O port
P121
P122
P123
P124
P125
P126
P127
PA0
PA1
PA2
PA3
PA4
PA5
PA6
PA7
PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PX5
PX6
PX7
Input/output mode can be specified in 1-bit units
INTP150
INTP151
INTP152
INTP153/ADTRG
A0
I/O
I/O
I/O
Port A
8-bit I/O port
A1
Input/output mode can be specified in 1-bit units
A2
A3
A4
A5
A6
A7
Port B
A8
8-bit I/O port
A9
Input/output mode can be specified in 1-bit units
A10
A11
A12
A13
A14
A15
Port X
REFRQ
WAIT
CLKOUT
3-bit I/O port
Input/output mode can be specified in 1-bit units
13
