DDR3(L)-2Gb SDRAM
NT5CB(C)256M8JQ/NT5CB(C)128M16JR
AC & DC Operating Conditions
Recommended DC Operating Conditions
Rating
Symbol
Parameter
Unit
Note
Min.
Typ.
Max.
DDR3
DDR3L
DDR3
1.425
1.5
1.575
1,2
VDD
Supply Voltage
V
1.283
1.425
1.283
1.35
1.5
1.45
1.575
1.45
3,4,5,6,7
1,2
VDDQ
Supply Voltage for Output
V
DDR3L
1.35
3,4,5,6,7
Note:
1. Under all conditions VDDQ must be less than or equal to VDD.
2. VDDQ tracks with VDD. AC parameters are measured with VDD and VDDQ tied together.
3. Maximun DC value may not be great than 1.425V.The DC value is the linear average of VDD/ VDDQ(t) over a very long period of
time
(e.g., 1 sec).
4. If maximum limit is exceeded, input levels shall be governed by DDR3 specifications.
5. Under these supply voltages, the device operates to this DDR3L specification.
6. Once initialized for DDR3 operation, DDR3L operation may only be used if the device is in reset while VDD and VDDQ are
changed for DDR3L operation.
7. VDD= VDDQ= 1.35V (1.283–1.45V )
Backward compatible to VDD= VDDQ= 1.5V ±0.075V
Supports DDR3L devices to be backward com-patible in 1.5V applications
Version 1.4
05/2019
85
Nanya Technology Cooperation ©
All Rights Reserved.
