DDR3(L)-2Gb SDRAM
NT5CB(C)256M8JQ/NT5CB(C)128M16JR
Overshoot and Undershoot Specifications
AC Overshoot/Undershoot Specification for Clock, Data, Strobe and Mask
1600
1866
2133
Unit
V
Maximum peak amplitude allowed for overshoot area
Maximum peak amplitude allowed for undershoot area.
Maximum overshoot area above VDD
0.4
0.4
0.4
0.4
0.4
0.4
V
0.13
0.13
0.11
0.11
0.10
0.10
V-ns
V-ns
Maximum undershoot area below VSS
NOTE 1. The sum of the applied voltage (VDD) and peak amplitude overshoot voltage is not to exceed absolute maximum DC ratings
NOTE 2. The sum of applied voltage (VDD) and the peak amplitude undershoot voltage is not to exceed absolute maximum DC ratings
Maximum Amplitude
Overshoot Area
VDDQ
VSSQ
Undershoot Area
Maximum Amplitude
Time (ns)
