Continued from the preceding page.
4. Reflow Soldering
When sudden heat is given to the components, the
[Standard Conditions for Reflow Soldering]
mechanical strength of the components should go down
Infrared Reflow
because remarkable temperature change causes
deformity of components inside. In order to prevent
mechanical damage in the components, preheating
should be required for both of the components and the
PCB board. Preheating conditions are shown in Table 1.
It is required to keep temperature differential between the
soldering and the components surface (∆T) as small as
possible.
Temperature (D)
Peak Temperature
200°C
Soldering
Gradual
Cooling
∆T
170°C
150°C
130°C
Preheating
Solderability of Tin plating termination chip might be
deteriorated when low temperature soldering profile
where peak solder temperature is below the Tin melting
point is used. Please confirm the solderability of Tin
plating termination chip before use.
Time
60-120 seconds 30-60 seconds
Vapor Reflow
Temperature (D)
When components are immersed in solvent after
mounting, be sure to maintain the temperature difference
(∆T) between the component and solvent within the
range shown in the Table 1.
Soldering
Peak Temperature
Gradual
Cooling
∆T
170°C
150°C
130°C
Table 1
Preheating
Part Number
G--18/21/31
Temperature Differential
∆TV190D
G--32/42/43/52/55
∆TV130D
Time
20 seconds max.
60-120 seconds
Recommended Conditions
Pb-Sn Solder
Infrared Reflow Vapor Reflow
[Allowable Soldering Temperature and Time]
Lead Free Solder
Peak Temperature
Atmosphere
230-250°C
230-240°C
240-260°C
270
260
250
240
230
Air
Air
Air or N2
Pb-Sn Solder: Sn-37Pb
Lead Free Solder: Sn-3.0Ag-0.5Cu
0
30
60
90
Soldering Time (sec.)
In case of repeated soldering, the accumulated
soldering time must be within the range shown above.
Optimum Solder Amount for Reflow Soldering
Overly thick application of solder paste results in
excessive fillet height solder.
[Optimum Solder Amount for Reflow Soldering]
This makes the chip more susceptible to mechanical and
thermal stress on the board and may cause cracked
chips.
0.2mm min.
Too little solder paste results in a lack of adhesive
strength on the outer electrode, which may result in chips
breaking loose from the PCB.
in section
18
Make sure the solder has been applied smoothly to the
end surface to a height of 0.2mm min.
Inverting the PCB
Make sure not to impose an abnormal mechanical shock on
the PCB.
