!Caution
Caution (Soldering and Mounting)
1. Vibration and Impact
2. Circuit Board Material
Do not expose a capacitor to excessive shock or vibration
during use.
It is possible for the chip to crack by the expansion and
shrinkage of a metal board.
Please contact us if you want to use our ceramic
capacitors on a metal board such as Aluminum.
3. Land Layout for Cropping PC Board
Choose a mounting position that minimizes the stress imposed on the chip during flexing or bending of the board.
[Component Direction]
[Chip Mounting Close to Board Separation Point]
C
Perforation
Locate chip
B
Chip arrangement
Worst AGCGB~D Best
horizontal to the
direction in which
stress acts.
D
A
Slit
<Example
<Examples
to be avoided>
of improvements>
Continued on the following page.
