Chip Monolithic Ceramic Capacitors
Medium Voltage Low Dissipation Factor
e
g
e
■ Features
1. Low-loss and suitable for high frequency circuits
2. Murata's original internal electrode structure
realizes high flash-over voltage.
L
W
3. A new monolithic structure for small, surface-
mountable devices capable of operating at high
voltage levels
Dimensions (mm)
T
Part Number
L
W
e min. g min.
GRM21A
GRM31A
GRM31B
GRM32A
GRM32B
GRM42A
2.0 ±0.2 1.25 ±0.2
0.7
1.0 +0,- 0.3
3.2 ±0.2 1.6 ±0.2
4. Sn-plated external electrodes realize good
solderability.
1.25 +0,- 0.3
1.0 +0,- 0.3
1.25 +0,- 0.3
1.5*
0.3
3.2 ±0.2 2.5 ±0.2
4.5 ±0.3 2.0 ±0.2 1.0 +0,- 0.3
2.9
5. Use the GRM21/31 type with flow or reflow soldering,
and other types with reflow soldering only.
* GRM31A7U3D, GRM32A7U3D, GRM32B7U3D : 1.8mm min.
■ Applications
Ideal for use on high frequency pulse circuits such
as snubber circuits for switching power supplies,
DC-DC converters, ballasts (inverter fluorescent
lamps), etc.
9
Do not use these products in any Automotive
Power train or Safety equipment including Battery
charger for Electric Vehicles and Plug-in Hybrid.
Only Murata products clearly stipulated as
"for Automotive use" on its catalog can be used
for automobile applications such as Power train and
Safety equipment.
*: In case of use C0G char., DC630V product with
pulse voltage, be sure not to use with 10kHz and
less pulse or ripple voltage condition.
and these product are not suitable for commercial
power line voltage application, such as AC filter.
For those applications, be sure to use AC voltage
rating product.(GA2/GA3 series)
C0G Characteristics
Electrode g
Rated Voltage
(V)
TC Code
(Standard)
Capacitance
(pF)
Length L Width W Thickness T
Electrode e
(mm)
Part Number
min.
(mm)
(mm)
(mm)
(mm)
GRM31A5C2J101JW01D
GRM31A5C2J121JW01D
GRM31A5C2J151JW01D
GRM31A5C2J181JW01D
GRM31A5C2J221JW01D
GRM31A5C2J271JW01D
GRM31A5C2J331JW01D
GRM31A5C2J391JW01D
GRM31A5C2J471JW01D
GRM31A5C2J561JW01D
GRM31B5C2J681JW01L
GRM31B5C2J821JW01L
GRM31B5C2J102JW01L
DC630
DC630
DC630
DC630
DC630
DC630
DC630
DC630
DC630
DC630
DC630
DC630
DC630
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
100 ±5%
120 ±5%
150 ±5%
180 ±5%
220 ±5%
270 ±5%
330 ±5%
390 ±5%
470 ±5%
560 ±5%
680 ±5%
820 ±5%
1000 ±5%
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.0
1.0
1.5
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.25
1.25
1.25
