!Caution
Continued from the preceding page.
(2) Example of a suitable machine
An outline of a printed circuit board cropping
machine is shown as follows. Along the lines with
the V-grooves on printed circuit board, the top
and bottom blades are aligned to one another
when cropping the board.
[Outline of Machine]
Top Blade
The misalignment of the position between top and
bottom blades may cause the capacitor to crack.
Printed Circuit Board
Top Blade
[Principle of Operation]
[Cross-section Diagram]
Bottom Blade
V-groove
Printed Circuit Board
V-groove
Not Recommended
Recommended
8
Top-bottom Misalignment
Left-right Misalignment
Front-rear Misalignment
Top Blade
Top Blade
Top Blade
Top Blade
Bottom Blade
Bottom Blade
Bottom Blade
Bottom Blade
150
